Bosch Fingerprint Reader White, CM729B

Bosch CM729B Fingerprint Reader in white, allow access to turn on or off your Bosch control panel via the fingerprint scanner, for internal use only, ideal for businesses.

Model : CM729B

The additional of a fingerprint reader to your installation will allow users to turn areas on and off or open a door simply by presenting their unique fingerprint credential to the reader.

Specifications

• Separate indicators show door and alarm status; built in sounder provides alarm warning
• Lock output and egress input to simplify wiring, with built in tamper switch
• Haptic feedback enhances user operation
• Adjustable volume control
• Anti replay and anti substitution protection

The fingerprint reader features 3D pixel sensing technology and can read virtually any finger; wet or dry. The sensors hard-coating protects against scratches, impacts and everyday wear-and-tear and provides in excess of 15KV electrostatic discharge isolation. The fingerprint reader includes red, green and blue indicators which are used to show area or door lock status at all times. To simplify installation, an egress input and lock output are also provided.

Unlike other systems, the readers are fully integrated with the control panel, which means that fingerprint credentials are automatically transferred between other readers on the system, reducing programming and installation time. Credentials can also be uploaded using the Solution Link RAS software for backup purposes and can even be copied from one panel to another, simplifying configuration for users with multiple sites. Various options can be configured via the Devices Keypad & Reader menu in panel programming. User access events are stored in the panel log and can also be reported if required.

Functions

A large blue reader status indicator is provided in the finger placement area to simplify user enrollment and day to day operation. The readers also include haptic technology that takes advantage of the users sense of touch by applying vibrations to the users finger during analysis and enrollment of fingerprint credentials.

Certifications and approvals

Code: N12138CE: EN 55022:2010, EN60950-1:2001

Tele permit: PTC 211/12/017

Technical specifications

• Power Requirements Operating
• Voltage: 10.0V DC 14.5V DC @ 100mAConnections
• Format: Proprietary Lock Output:
• Protected open collector transistor output 500mAEgress Input: Love (Ov) to trigger.
• Can be disabled via software control
• Environmental Considerations Temperature: -30o to 55oC
• Operating Humidity: 5% to 85% at 30oC non-condensing
• Enclosure Dimensions: 74(W) x 23(D) x 116(H)mm
• Warranty: 3 years
