Description
Best For
Professionally planned alarm upgrades where a new Solution 6000 control board and colour smart-card keypad are required, with suitable existing components retained after installer assessment.
The Bosch CC610GWP bundle combines a Solution 6000 CC610P control PCB with a white CP736B 3.5-inch colour smart-card keypad. It provides the core control and user interface for an alarm upgrade. An enclosure, power equipment and other system components are purchased separately.
Key Features
- 16 onboard zones, expandable to 144 with suitable additional hardware
- Up to 8 areas and 990 users
- 5 onboard outputs, expandable to 37
- White CP736B keypad with colour display, illuminated keys and built-in smart-card reader
- PIN or compatible enrolled smart-card operation
What Is Included?
- 1 × Solution 6000 CC610P control panel PCB
- 1 × white CP736B 3.5-inch colour keypad and mounting backplate
- Manufacturer manuals and panel resistor/accessory pack, including battery leads and panel tamper components
Purchased separately: metal enclosure, transformer or plug pack, backup battery, detectors, sirens, cabling, communications modules, smart cards or tokens, installation and programming. The pack does not include a metal box or a choice of black and white keypads.
Compatibility and Upgrade Planning
Your installer should assess existing detectors, sirens, wiring, enclosure and power equipment before deciding what can be reused. Replacing the board requires system configuration and testing; existing programming does not automatically transfer.
Confirm enclosure fit, connected-device support and the firmware required for the CP736B before installation. Wireless devices, additional zones and access-control functions require the appropriate receivers, expanders or door hardware.
Power, Communications and App Setup
The panel requires a suitable 16–18 V AC, 24 VA supply and a compatible 12 V backup battery. The keypad receives power through the panel LAN connection. Your installer must check the total system load and battery requirements.
The CP736B has no built-in Wi-Fi. Remote app access requires compatible communications hardware, an internet or mobile service, installer configuration and account activation. Confirm the selected app and any service fees before ordering; app access is not supplied by this bundle alone.
Downloads and Related Products
Bosch CC610GWP bundle datasheet
Browse Bosch Solution 6000 systems and accessories or compare Solution 6000 upgrade kits.
Plan Your Alarm Upgrade with CTC Communications
Australia-wide delivery is available. Contact CTC Communications for compatibility advice and professional Sydney installation before purchasing an upgrade bundle.
