Description
The DS-PM1-O1L-WB relay module with small case design, which can be put into hiding places easily automation operating, one button turn on/off from APP/Keyfob/Keypad.
Model: DS-PM1-O1L-WB
Features
- 433MHz two-way wireless communication
- AES-128 encryption
- LED display, show status of device and replay on/off display
- Small case design, which can be put into hiding places easily
- Automation operating, one button turn on/off from APP/Keyfob/Keypad
- Setting scenarios by different events
- With one tamper input, can be used as zone input for alarm
Specifications
- Learning Button1, For register
- Scenario Setting By Alarm, By Operation, By Fault, By Schedule, By Manual
- Hardware Features
- Alarm Input1 for tamper, NO/NC
- Relay Output1, NO/NC (0~36V DC, Max 5A）
- Serial Port1, for debug
- RF Transmission
- RF Method Two way communication
- RF Modulation2GFSK
- RF Frequency433MHz
- RF Distance800m
- Wireless SecurityAES-128
- Electrical Characteristics
- Power Supply DC 7V – 24V
- Display
- LEDs Status3, Register/Signal (Green/Red), Power (Green), Relay Status (Blue)
- General
- Operation Temperature﹣10℃~+55℃
- Operation Humidity10％~90％
- Shell Material Plastic
- Dimension(WxHxD)38x25x18mm
- 28.5g
- Color White
- Installation Method Wall Mounting
Downloads
Hikvision Wireless Relay Module, DS-PM1-O1L-WB Datasheet
Hikvision Wireless Alarm Brochure
Warranty
Hikvision Alarm Systems products are covered by a 2 years Manufacturer Warranty from the date of purchase.
CTC Security offers a 1 year warranty on labour when the system is installed by us.
Customer to cover warranty postage for any replacement parts.
