Description
Wireless curtain detector, slim design for window frame installation, weather resistant, fully supervised.
Model: DS-PDC10DM-EG2- WB
Features
- Slim design for window frame installation
- IP65 weather resistance for outdoor application
- Active IR anti-masking
- Directional detection support
- Multiple enrollment methods and easy installation
- Frequency hopping against jamming for reliable transmission
Specifications
- Passive Infrared; Microwave
-
Detection Range
Wall Mount：10m
Ceiling Mount：5m
- Detection Angle5°
- Detection Zones32
- Detectable Speed0.3～2m/s
- Sensitivity Auto; Pet
- White Light Filter6500lux
- Microwave Frequency24GHz(24.15～24.25GHz)
-
Pet Immunity
Wall Mount：12Kg
Ceiling Mount None
- Digital Temperature Compensation Support
- Creep Zone Protection Support
- Anti-Masking Support
- Feature
- Digital Processing Support
- Sealed Optics Support
- Tamper Protection Front; Rear
- Environment Temperature Indicator Support
- Signal Strength Indicator Support
- Directional Detection Support
- Interface
- Power Switch Power Up Enrolling
- LED Indicator Green(PIR), Red(Microwave), Green+ Orange(Mask), Blue(Alarm)
- Transmission
- Transmission Technology Tri-X Wireless
- Transmission Method Two-Way RF Wireless
- Transmission Frequency433MHz
- Transmission SecurityAES-128 Encryption
- Transmission Range(Free Space)1Km
- Frequency Hopping Support
- Enrolling Method Power up; Remote ID;QR Code
- Electrical Characteristics
- Standard Battery Life5 years in work status (being triggered 20 times per day)
- Power Supply Battery Powered
- Battery TypeCR123A × 2
- Typical Voltage3V
- General
- Operation Temperature-10 °C to 55 °C (14 °F to 131 °F)
- Storage Temperature-20 °C to 60 °C (-4 °F to 140 °F)
- Operation Humidity10% to 90%
- IP RateIP65
- Dimension(WxHxD)29.2mm × 134.4mm × 39.5mm
- 120g
- Mounting Height2 to 3.5m
- Mounting Method Wall; Ceiling
- Application Scenario Indoor, Outdoor
- Bracket L-shaped adapter included
