HiLook 8 Channel Digital Video Recorder, DVR-208U-M1

HiLook digital video recorder DVR-208U-K1 can connect up to 8 channel high definition analogue cameras, DVR includes one bay for hard disk drive, no hard drive included.

Model: DVR-208U-K1

Digital Video Recorder Features

8-ch 5 MP 1U H.265 Digital Video Recorder

• 5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP)
• Long distance transmission over UTP and coaxial cable
• H.265 Pro+ compression to improve encoding efficiency and reduce data storage costs
• Encoding ability up to 8 MP @ 8 fps
• One HDD for continuous video recording
• Smart search for efficient playback.

Specifications

• Perimeter Protection
• Line Crossing Detection/Intrusion Detection

  2-ch

  Enhanced VCA mode on: 8-ch

• Recording
• Video CompressionH.265 Pro+/H.265 Pro/H.265/H.264+/H.264
• Encoding Resolution

  When 8 MP Lite mode is not enabled:

  8 MP/5 MP/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF

  When 8 MP Lite mode is enabled:

  8 MP Lite/3MP/1080P/720P/WD1/4CIF/VGA/CIF

• Frame Rate

  Main stream:

  When 8 MP Lite mode is not enabled:

  8 MP@8 fps/5MP@12 fps/4 MP@15 fps/3 MP@18 fps

  1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)

  When 8 MP Lite mode enabled:

  8 MP Lite/3MP/1080P/720P/WD1/4CIF/VGA/CIF@15 fps

  Sub-stream:

  WD1/4CIF/CIF@25fps (P)/30fps (N)

• Video Bitrate32 Kbps to 10 Mbps
• Dual-Stream Support
• Stream Type Video, Video & Audio
• Audio CompressionG.711u
• Audio Bitrate64 Kbps

• Video And Audio
• IP Video Input

  4-ch (up to 12-ch)



  Enhanced IP mode on:

  8-ch (up to 16-ch), each up to 4 Mbps

  Up to 8 MP resolution

  Support H.265+/H.265/H.264+/H.264 IP cameras

• Analog Video Input

  8-ch

  BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection

• HDTVI Input8 MP, 5 MP, 4 MP, 3 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25
• AHD Input5 MP, 4 MP, 1080p25, 1080p30, 720p25, 720p30
• HDCVI Input4 MP, 1080p25, 1080p30, 720p25, 720p30
• CVBS InputPAL/NTSC
• HDMI Output1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
• VGA Output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
• Audio Input

  1-ch, RCA (2.0 Vp-p, 1 KΩ)

  8-ch via coaxial cable

• Audio Output1-ch, RCA (Linear, 1 KΩ)
• Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the audio input)
• Synchronous Playback8-ch

• Network
• Remote Connection64
• Network Protocol TCP/IP, PPPoE, DHCP, HiLook Vision, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
• Network Interface

  1, RJ45 10/100/1000 Mbps self-adaptive

  Ethernet interface

• Auxiliary Interface
• SATA1 SATA interface
• Capacity Up to 10 TB capacity for each disk
• USB Interface Real panel: 2 × USB 2.0
• Alarm In/Out N/A

• General
• Power Supply12 VDC, 1.8 A
• Consumption≤ 20 W (without HDD)
• Working Temperature-10 °C to +55 °C (+14 °F to +131 °F)
• Working Humidity10% to 90%
• Dimension (W × D × H)260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch)
• ≤ 1.2 kg (2.6 lb)

Downloads

DVR-208U-K1 Datasheet
