Description
The Optex motion detector FMX-DT is a high performance 15M 85 Degrees Dual Technology (PIR & MW) indoor detector for high-end residential and light commercial installations.
Model: FMX-DT
Optex Motion Detectors are designed to detect the presence of moving objects within the vicinity. Dual Tech FMX-DT utilizes two detection technologies for superior accuracy, with up to 97% coverage.
Motion Detector Features
- Complies with EN50131-2-4
- Digital quad zone logic
- Silent output
- Advanced sealed optics
- Advanced temperature compensation logic
- Remote LED control - Selectable plug-in end of line unit (option)
- Microwave area shaping technology
Shop CTC Security for best deals on Hills Security Alarm Systems
Specifications
| Model | FMX-DT |
| Detection method | Passive Infrared + Microwave |
| Coverage | 15 m x 15 m 85°wide |
| Detection zones | 78 zones |
| Mounting height | 2.2 to 3.0 m |
| LED alarm indicator | Switchable ON/OFF |
| Alarm period | Approx. 2.5 sec |
| Alarm output | N.C., 28 VDC 0.2 A max. |
| Tamper switch | N.C., Open when cover is removed. |
| Tamper output | 28 VDC 0.1 A max. |
| Sensitivity/range | Switchable LOW/MID/HI |
| Microwave sensitivity/range | Switchable LONG/SHORT |
| Warm up period | Approx. 60 sec (LED blinks.) |
| Power input | 9.5 to 16 VDC |
| Current draw | 12 mA (normal), 15 mA (max.) at 12 VDC |
| Dimensions(H x W x D) | 111.7 mm x 61.4 mm x 50.0 mm |
| Weight | 120 g |
| Operating temperature | -20 to +45°C |
| Environmental humidity | 95% max. |
| RF interference | No alarm 10 V/m |
Downloads
Optex Motion Detector Dual Tech, FMX-DT Datasheet
Hills Reliance XR Datasheet
