Description
Hikvision's Module Door Station Rain Shield, DS-KABD8003-RS1
Model: DS-KABD8003-RS1
Shop CTC Security for best deals on Intercoms for Home
Specifications
- Working Temperature: -40° C to +60° C (-40° F to 140° F)
- Working Humidity: 10% to 95%
- Weight: 298.9g
- Dimension (W × H × D): 122x 116.4×58 mm (4.80" x 4.58" x 2.28")
- Material: SECC
Installation
1. Paste the installation Sticker 1 onto the wall. Make sure the sticker is placed leveled via measuring with the gradient. Drill 4 holes align to the screw holes on the sticker.
The suggested size of the hole is 6 (diameter) × 25 (depth) mm.
2. Remove the sticker and insert the expansion sleeves into the screw holes. Fix the mounting frame and protective shield onto the wall with 4 expansion bolts.
3. Connect the cables to the corresponding interfaces of the main unit and insert them into the frame.
4. Use the hexagon wrench in the package to fix the cover onto the frame.
Downloads
Hikvision Rain Shield of Module Door Station, DS-KABD8003-RS1 Datasheet
Warranty
Hikvision Intercom products are covered by a 2 years Manufacturer Warranty from the date of purchase.
CTC Security will cover postage for all replacement parts, but will not cover labour for installation cost.
CTC Security offers a 1 year warranty on labour when the system is installed by us.
